Control and display elements
Butzbach GmbH Industrietore Original operating manual sliding doors_V1 13/01/2021 30
Track heating status notification
The indicator lights up if the track heating is turned on.
6.2.8 “SKS activated” indicator light (optional)
Front of the control cabinet
If it lights up: ensure that the person is removed from the hazard area or the object is removed
from the door area. Only after this has been done can the door be operated again.
Warning notification: the SKS at door leaf x has been activated.
The door leaf cannot be moved in the corresponding direction.
6.2.9 “Door closed” indicator light (optional)
Front of the control cabinet
Status notification for the building control system that the door is closed.
The indicator lights up if the door is completely closed.
The “Door closed” signal is sent to the building control system.
6.2.10 “Doors of door leaf X open” indicator light (optional)
Front of the control cabinet
If it lights up: close the doors in order to activate the door system again.
Warning notification: the door in door leaf x has been opened.
Door leaf x cannot be moved.
6.2.11 “Wind speed > 70 km/h” indicator light (optional)
Front of the control cabinet
The signal comes from the building control system.
The indicator lights up if the maximum allowed wind speed is exceeded.
The door may not be moved!
