12 Technical Data
12.1 Single-circuit units in the standard design *
Bewazon Ozone Unit VULW Type 12 25 45
Ozone generator Quantity 1 1 1
Rated ozone output according to DIN 19627 g/h 12 25 45
Ozone concentration as per DIN 19627 g/Nm³ 20
Gas used Air
Air quantity Nm³/h 0.6 1.25 2.25
Operating gas pressure bar, rel. -0.1 to 0.0
Ambient temperature °C 5 to 30
Max. relative humidity for devices with:
Standard design, at max. 30°C
Tropical design, at max. 40°C
%
%
60
60
Max. absolute humidity for devices with:
Standard design, at max. 30°C
Tropical design, at max. 40°C
g/Nm
3
g/Nm
3
20
40
Protection class IP53
Number of dryers 2
Desiccant per dryer kg 3
Transformers Pieces 1
Transformer capacity kVA 1.1 1.1 2.0
Specicenergyofstainlesssteelozonegenerator
at 50 / 70 / 100% of the rated ozone production
capacity
Wh/g 12 / 13 / 17
Operation with
50%
70%
100%
Ozone production
capacity
Electrical power consumed
with stainless steel ozone
generator including air drying
kW
kW
kW
0.1 0.20 0.36
0.13 0.28 0.50
0.23 0.48 0.86
SpecicenergyofPVCozonegenerator Wh/g - ≤ 25 ≤ 25
Ozone generation stainless steel/PVC, adjustable in steps 16 / 14
Operating voltage 1/N/PE ** V/Hz 230 / 50 / 60
Max. current consumption *** A 14 14 18
External overcurrent protection A, slow 20 20 25
Coolingwaterowat4-17°CWT L/h 30 40 70
Cooling water connection d (DN) 20 (15)
Ozone connection d (DN) 20 (15)
Cooling water pressure, stainless steel / PVC bar 8 / 1
Width, total unit mm 800
Height, plus 100 mm for connections mm 1900
Depth, plus 1000 mm clearance for door mm 500
Weight excl. packaging, approx., stainless steel kg 330 330 360
Weight excl. packaging, approx., PVC kg - 330 340
PNR Unit with stainless steel ozone generator 6-202193 6-202194 6-202195
PNR Unit with PVC ozone generator – 6-202206 6-202207
* a)Multi-circuitsystems:Deviationsfromindividualspecicationspossible.
b) Tropical units: Air humidity and air temperature requirements for the installation area are displayed
** Max. 13 to 14 levels are available at a mains frequency of 60 Hz.
*** Theindividualphasesdrawdi󰀨erentcurrents.
