Aperturefor
fasteningtheeye
tothewall
Aperturefor
fasteningtheeye
tothepanel
Holdthetemplateagainstthewallattheselectedinstallationsite,anddrillinthe4locationsindicatedby
thetemplateusinga5mmdiameterdrillbit.Pushthebushingsintotheholesandscrewaroundhead
screwintoeachbushingleavingittoprotrudeslightly.Hangthepanelontheroundheadscrewsusingthe
suspensioneyeholes.
!
Donotobstructtheowofairbehindthepanelthatallowscooling.
!
Donotinstallthecontrolpanelinacupboardorotherlocationwithinadequateventilation,thiscould
leadtooverheatingofthecontrolpanelandariskofre.
4.3 Electrical wiring
Wirethecontrolpanelinasfollows;
Connectthecellandthegassensortothecontrolpanel.NEVERMODIFYOREXTENDTHECABLES;
