2021/03 - Indice de révision : B Code : 29740TRAITEMENT DE L'EAU
81/88
7.6.1 InstallationdesWiFi-Moduls
EntfernenSiedieBlendedesWiFi-Moduls.
DurchtrennenSiedieKabelklemmen.
LösenSiedieKabel.
Führen Sie die Kabel vom Inneren des Moduls durch die
Kabeldurchführung.
SchließenSiedieKabelinderWiFi-Boxwiederan.
GND=Schwarz
CE=Grün
CA=Gelb
+12V=Rot
