13 2021/07 - Version: C -
Mounting the axle on the bearing side
Ref Description Qty
1 HSHC screw M8x35 A4 SS 4
2 Z8 washer A4 SS 4
Do not block the screws yet.
Mounting the axle on the throughwall flange side
Levelling the axle
Block the screws once the axle is horizontal.
