BWT STARDECK INEO - Axle, Diameter 250 MM

56 pages

Save Page as PDF

To Next Page

To Previous Page

PROTECTION & SAFETY

12 2021/07 - Version: C -

Code : 34681

Mounting the axle on the throughwall flange side

Levelling the axle

Block the bearing screws once the axle is horizontal.

2. Axle, diameter 250 mm

Product presentation:

Ref Description Qty

1 Protective pin 1

H14 nut A4 SS

3 W14 washer A4 SS 3

4 SS shaft, motor side 1

5 M14 H screws A4 SS 3

Feeding the stainless steel shaft through the throughwall flange from the pool to the motor pit
