PROTECTION & SAFETY
26 2021/07 - Version: C -
Code : 34681
The total length of the slat apron/ Inéo polyester connection strap is 2000mm, it features 3 axle fasteners. Select
the black fastener required depending on the depth of the axle.
Example: if the axle depth is 1000mm, trim the trap to obtain the 1000mm version.
2000 mm strap version
1000 mm strap version
250 mm strap version
After cutting the strap, heat the tip of the cut end.
Keep this fastener
Remove this fastener
Remove this fastener
Cut the strap
Remove this fastener
To obtain this
Cut the strap
To obtain this
