BYD ECB16 - Mast Specifications; Battery Specifications

ECB16 ECB18
37 OM-ECB162015006-EN-US
Mast Specifications
Type 2-Stage Standard 2-Stage Free Lift 3-Stage Free Lift
ECB16 ECB18
Lift height h3 in 118.1 137.8 157.5 177.2 118.1 137.8 157.5 177.2 196.9 216.5 236.2
Fork height h23 in 119.5 139.2 158.9 178.5 119.5 139.2 158.9 178.5 198.2 217.9 237.6
Height, mast lowered h1 in 79.5 89 98.8 110.6 79.5 91.3 101.2 80.5 88.4 96.3 104.1
Load backrest height h8 in 39.4 39.4 39.4 39.4 39.4 39.4 39.4 39.4 39.4 39.4 39.4
Height, mast extended (without load backrest) h4 in 142.7
162.4 1
82.1 201.8 141.9 161.6 181.3 202 221.7 241.3 261
Height, mast extended (with load backrest) h4 in 158.9 178.5 198.2 217.9 158.9 178.5 198.2 217.9 237.6 257.3 277
Free lift (without load backrest) h2 in 5.9 5.9 5.9 5.9 55.7 67.5 77.4 55.7 63.6 71.5 79.3
Free lift (with load backrest) h2 in 5.9 5.9 5.9 5.9 38.2 50 59.8 39.2 47 54.9 62.8
Tilt of mast/fork carriage forward/backward
α
/
β
deg 5/7 5/7 5/7 5/7 5/7 5/7 5/7 5/5 5/5 5/5 5/5
Load distance, center of d
rive axle to fork x i
n 14.4 14.4 14.4 14.4 14.4 14.4 14.4 15.6 15.6 15.6 15.6
Battery Specifications
Model ECB16B,ECB16C ECB18B,ECB18C
Battery voltage, nominal capacity V/Ah 80/230 80/270 80/230 80/270
Battery weight lb 1433.3 1433.3 1433.3 1433.3
