TRUCK VIEW AND TECHNICAL SPECIFICATIONS
OPERATOR MANUAL 36
Technical Specifications (Dual Drive)
Identification
1.1 Manufacturer BYD BYD
1.2 Model ECB16B,ECB16C ECB18B,ECB18C
1.3 Drive Electric Electric
1.4 Operator type Seat Seat
1.5 Rated capacity Q lb 3528 3969
1.6 Load center c in 19.69 19.69
1.7 Load distance, center of drive axle to fork x in 14.37 14.37
1.8 Wheelbase y in 53.54 53.54
Weight
2.1 Service weight lb 6835.5 7276.5
2.2 Axle load, with load, front/rear lb 9003.02/1360.49 9911.48/1334.03
2.3 Axle load, without load, front/rea
r lb 3232.53/3602.97 3419.96/3856.55
Wheels, Chassis
3.1 Tires SE SE
3.2 Tire size, front 18
×
7-8 18
×
7-8
3.3 Tire size, rear 15
×
4.5-8 15
×
4.5-8
3.4 Wheels, number front rear (X=driven wheels) 2x/2 2x/2
3.5 Track width, front b10 in 35.04 35.04
3.6 Track width, rear b11 in 7.48 7.48
Basic Dimensions
4.1 Tilt of mast/fork carriage forward/backward a/b deg 5/7 5/7
4.2 Height, mast lowered h1 in 79.53 79.53
4.3 Free lift h2 in 5.91 5.91
4.4 Lift height h
3 in 118.11 118.11
4.5 Height, mast extended h4 in 158.86 158.86
4.6 Height of overhead guard h6 in 80.71 80.71
4.7 Seat height h7 in 38.78 38.78
4.8 Coupling height h10 in 18.9 18.9
4.9 Overall length l1 in 115.55 118.31
4.10 Length to face of forks l2 in 76.18 78.94
4.11 Overall width b1 in 41.34 41.34
4.12 Fork dimensions s/e/l in 1.38/3.94/39.37 1.38/3.94/39.37
4.13 ISO 2328 2A 2A
4.14 Fork carriage width b3 in 40.94 40.94
4.15 Ground clearance, with load
, below mast m1 in 3.74 3.74
4.16 Ground clearance, center of wheelbase m2 in 3.74 3.74
4.17 Aisle width for pallets 1000x1200 crossways Ast in 136.22 138.98
4.18 Aisle width for pallets 800x1200 lengthways Ast in 140.94 143.7
4.19 Turning radius Wa in 61.81 64.57
4.20 Inward turning radius in 0 0
Performance Data
5.1 Travel speed, with/without load MPH 9.94/9.94 9.94/9.94
5.2 Lift speed, with/without load MPH 1118.47/1230.32 1118.47/1230.32
5.3 Lowering speed, with/without load MPH 1185.58/1118.47 1185.58/1118.47
5.4 Max. drawbar pull, with/without load lb 2023.29/1776 2023.29/1798.48
5.5 Max. gradeability, with/without load % 20/20 18/20
5.6 Acceleration time, with/without load s 4.5/4.0 4.5/4.0
5.7 Service brake Mech./Hydr. Mech./Hydr.
Motor
6.1 Drive motor rating S2 60 min. kW 5
×
2 5
×
2
6.2 Lift motor rating at S3 15% kW 16 16
Others
7.1 Type of drive control AC AC
7.2 Operating pressure for attachments psi 2320.6 2610.68
7.3 Sound level at the driver's ear dB(A) 65 65
7.4 Towing coupling, type PIN PIN
