REGULAR INSPECTION AND MAINTENANCE
OPERATOR MANUAL 86
Return Filter Element Replacement
1. Put the clean cloth around the return filter.
2. Unscrew the cover plate and pull the out filter element.
3. Clean the cover plate and check if the seal and the o-ring are in good condition, replace
them if necessary.
4. Check if the spread and the o-ring of the new element are in good condition, replace
them if necessary.
5. Use clean hydraulic oil to lubricate the the o-ring of the new element, fit the new element
carefully and screw the cover plate.
6. After replacement, operate the hydraulic system to check if there is any leakage.
Element
Element O-ring
O-ring
Cover Plate
Seal
