ECB16 ECB18
87 OM-ECB162015006-EN-US
High Pressure Filter Element Replacement(Comfort Type Forklift)
1. Put the clean cloth around the return filter.
2. Unscrew the filter bowl and pull the out filter element.
3. Clean the filter bowl and check if the o-ring is in good condition, replace it if necessary.
4. Check if the spread and the o-ring of the new element are in good condition, replace
them if necessary.
5. Use clean hydraulic oil to lubricate the the o-ring of the new element, fit the new element
carefully.
6. Screw in the filter bowl fully and then unscrew by one quarter-turn.
7. After replacement, operate the hydraulic system to check if there is any leakage.
Element
Element O-ring
O-ring
Retaining Ring
Filter Bowl
Check and Replace the Air Filter
Check the air filter and replace it if necessary.
Air Filter
