Operator manual
Page 9 - 13
Initial version : 11/08
Lastest revision : 02/10
Work envi• ronment:
Temperature: 10°C (50°F) through 32°C (89.6°F)
Relative humidity: 40 through 85% RH
Power consumption:•
BTU output: from 2525 to 5700 BTU/H (complete system).•
Noise level: 70 db.•
Warning: Never remove the power cord while the machine is turned ON.
General
- Input/Output paper path: 860 mm without ITE and 610 mm with ITE.
- Variable speed of input motor.
- Centered registration: the BME positions itself to the center of the processed paper
format from the upstream registered equipment thanks to a transversal motorization.
- Full automatic adjustment depending on the format.
- Upper reception tray for top/edge/corner stitched booklet or poor booklet.
- Paper path jam, open baffles and open covers detectors.
- Detection of output conveyor full and trim waste container full.
- Machine is managed via the U.I.
- Different component position (heads/stops/joggers/PA press/TR press/holding wheels/
conveyor motion) is automatic depending on the defined job in the U.I.
- Fine adjustments possible while machine is working.
Stitcher
- The BME is equipped with 2 or 4 stitching heads.
- Equipped with ISP stitching heads featuring toolless change over self threading cassette
for stitch wire supply.
- On demand before delivery, the machine can be equipped with 2 or 4 Hohner heads
compatible with various diameter wire.
- Hohner heads convertible to loop stitch model via optional upgrade kit.
- Heads supplied with wire n°25 (EU) or 25 Gauge (US).
- Capacity of 50.000 stitches (75 gsm, 2 to 30 sheets).
Folder
- Booklets folded between the belts with a fold crush device.
- Booklet pressure adjustment.
Trimmer
- Upper and lower knives, without heel, can be easily replaced.
- Equipped with a system to ease the ejection of the chips.
- Waste bin that can be emptied while machine is working.
Consumption
Machines
Maximum In operation
230 V
50Hz
120 V
60Hz
230 V
50Hz
120 V
60Hz
AGR-PA 994 W 924 W 740 W 760 W
AGR-PA-TR 1675 W 1480 W 1110 W 1160 W
