C.P.Bourg BM-e - 3.3 BME description; 3.3.1 Technical characteristics

Operator manual
Page 9 - 12
Initial version : 11/08
Lastest revision : -
3.3 BME description
3.3.1 Technical characteristics
Verify that you electrical service corresponds with one of the following:
USA 120V AC +/- 10% - 60Hz
EUROPE 230V AC +/- 10% - 50Hz
JAPAN 230V AC +/- 10% - 60Hz
Check your environmental conditions.
This machine is designed for the following environment:
Storage and transport:•
Temperature: -34°C through 60°C / -30°F through 140°F
Relative humidity: 5 through 90% RH
Altitude: -31m through 12 192m / -100 ft.through 40 000 ft.
Atmospheric pressure: ≥ 56kPa (420mm Mercury)
User interface
Output conveyor
Input
REAR
LEFT
RIGHT
Operator side
FRONT
Upper reception tray
Stitcher (AGR)
ITE with BSTd
+
/BST-e
Folder (PA)
Trimmer (TR)
optional
Pedal to activate the
motion of the
conveyor (only
available with TR
module)
Output
