3.4 Key Functions
The key functions depend on the current printer state:
- Active functions: Labels and symbols on the navigator pad keys light up.
- Active functions light up white in print mode (e. g. menu or feed).
- Active functions light up orange in the ofine menu (arrows, key 8 ).
Key Display State Function
menu lights
Ready
Ready To the ofine menu
feed lights
Ready
Ready Feeds a blank label
pause lights
Printing label
Printing label Interrupt print job,
printer goes into "Pause" state
Pause
Pause Continue the print job,
printer goes into "Printing label" state
ashes
Correctable error Continue the print job after rectifying the error,
printer goes into "Printing label" state
i
Notice : The labels, which are printed by the
lower printer but not yet printed by the upper
printhead when the error occurs, cannot be
repeated by the printer. So the amount of the
printed label will be reduced within the print job.
cancel lights
Printing label
Printing label
Short press g
cancels the current print job
Longer press g cancels the current print job
and deletes all print jobs
Pause
Pause
Correctable error
ashes
Irrecoverable error
8
lights
Error Call Help - Concise information for rectifying the
fault will be displayed
Table 3 Key functions in the print mode
Key Menu Parameter setting
Parameter choice Numeric value

Return from a submenu - Increase of the number at the
cursor position

Jump into a submenu - Decrease of the number at the
cursor position

Menu option to the left Sheets to the left Cursor shift to the left

Menu option to the right Sheets to the right Cursor shift to the right
8
Start of a selected menu option
Pressing 2 s: Leaving the ofine menu
Conrmation of the selected value
Pressing 2 s: Abort without changing the value
Table 4 Key functions in the ofine menu
