CAB XC Series - Installation; Device Overview

6 6
2.1 Device Overview
12
7
9
6
2
1
3
5
8
10
4
11
1 Display
2 Navigator pad
3 Peripheral port (covered)
4 Print mechanics
5 Flap
6 Cover
7 Upper ribbon take-up hub
8 Upper ribbon supply hub
9 Roll retainer
10 Lower ribbon take-up hub
11 Swing arm with guide roller
12 Lower ribbon supply hub
Fig. 1 Overview
16
15
14
13
13 Upper ribbon deection
14 Printhead retainer with upper printhead
15 Upper print roller
16 Upper printhead locking lever
Fig. 2 Print mechanics - upper print unit for printing the main color
2 Installation
