7
22
19
18
17
21
20
23
17 Lower ribbon deection
18 Printhead retainer with lower printhead
19 Lower print roller
20 Label sensor
21 Guide roller with guide ring
22 Guide roller
23 Lower printhead locking lever
Fig. 3 Print mechanics - lower print unit for printing the secondary color
24
25
26
27
28
29
30
31
24 Power switch
25 Power connection jack
26 Slot for PC Card Type II
27 Slot for CompactFlash memory card
28 Ethernet 10/100 Base-T
29 2 USB master ports for keyboard,
scanner or service key
30 USB high-speed slave port
31 Serial RS-232 C port
(not to be used 5.5 on page 19)
Fig. 4 Connections
2 Installation
