Part# Description
1 Porcelain-Coated Steel Upper Cooking Rack
2 Porcelain-Coated Cast-Iron Cooking Grids (x2)
3 Lid Stopper
4 Chimney Cap
5 Chimney Stack
6 Flame Broiler Slider
7 Flame Broiler Main Plate
8 Meat Probe (x1)
9 Main Barrel / Hopper Assembly
10 Lid Handle
11 Support Plate
12 Side Shelf
13 Sear Station Handle
14 Sear Station Arm
15 Locking Caster Wheel (x2)
16 Wheel (x2)
17 Support Leg For Locking Caster Wheel (x2)
18 Support Leg For Wheel (x2)
19 Grease Bucket
20 Bottom Shelf
21 Screw (x18)
22 Washer (x18)
23 Locking Washer (x18)
24 Nut (x2)
25 Wheel Washer (x4)
26 Wheel Axle Pin (x2)
27 Screw (x4)
28 Screw (x4)
NOTE: Due to ongoing product development, parts are subject to change
without notice.
1
2
6
3
4
5
10
11
12
13
15
17
18
19
20
16
8
9
7
14
171
172
181
182
23
25
27
22
21
24
26
28
