Function List
LEVEL 4
Access to level 4 is gained through VER in level 3.
Press and hold ▲ and ▼ for 10 seconds.
Enter level 4 at
Lock
, release ▲ and ▼ together. Display
will alternate LOCK and
nonE
Program security using Lock
Select from three
Lock
options:
Press and hold ✱, press ▲ to index.
LEV.3
locks level 3 and 4 only- Technical Functions.
LEV.2
locks levels 2, 3 and 4 only - Configuration and
Technical Functions.
ALL
locks all functions (unrestricted
LEVL, VEr,
TECH
, SP.LK
)
Note: Locked functions and options may be read.
Press ▼ to access following functions
PROG
[Auto] StAY
Program mode auto-exit switch
Auto-exit returns display to normal if 60 seconds of key
inactivity, select
StAY
to disable
NO.AL
[oFF] on
Disable SP2 alarm annunciator -AL-
Select on to disable -AL-
DIS.S
dir 1 to 32 [6]
Display sensitivity
dir
= direct display of input
1
= maximum,
32
= minimum sensitivity
DER.S
0.1 to 1.0 [0.5]
Derivative sensitivity
21
IMPORTANT NOTE FOR OEM’s: For safety and to protect settings from tampering
USE THE SOFTWARE SECURITY LOCK.... THEN REMOVE THIS SECTION.
✂
