Operating instructions
EVS17/07-DS/IU und EVS17/12-DS/IU
Trautmann GmbH & Co. KG -ApparatebauCALIRA
Lerchenfeldstr. 9 87600 Kaufbeuren Tel.08341/9764-0 Fax 08341/67806
Internet: http://www.calira.de Email: info@calira.de
37
Maintenance instructions
Procedures in the event of faults
Clean the device and the ventilation slots with a dry, lint-free cloth.
The device is maintenance-free. However, if any faults do occur, please proceed
according to the following table:
The device is not Check the circuit breaker and the mains connection
working.
The battery is not Check the battery connection, ensuring correct polarity.
being charged. Unplug the mains plug of the device and reinsert it.
12 V circuits are Check the fuses and replace them if necessary. Check
not being supplied. the connections to the affected circuits.
The voltage of Start the motor and let it run for ca. 30 seconds. Bat-
battery 2 has drop- tery voltage rises above 1,5 V. The charging process
ped below 1.5 V. starts automatically.
The device is over- The thermal switch was triggered. Wait for a few mi-
heating and is not nutes until the device has cooled down.
working.
None of the faults Please contact the manufacturer:
described here seems Trautmann GmbH & Co. KG
to apply. But the CALIRA-Apparatebau
device still does Lerchenfeldstr. 9
not work. D-87600 Kaufbeuren
Service telephone: 0190/77 03 80
Fault Action
(1,24 /min.)
The device must always be disconnected from
the mains before any maintainance!
