Required Items

Verify that the following items are on hand before you begin the installation.

Calix-supplied items

The Calix E7-2 installation package includes the following items:

Qty Description

1 Calix E7-2 two-slot chassis (1 RU)

1 Calix E7-2 fan module

1 Calix E7-2 blank line card

4 Rack mounting ears; 19-inches (48.26-cm) (2 ea.) and

23-inches (58.42-cm) (2 ea.)

8 Flathead Phillips screws, 4-40 x .1875 inches (.6 cm)

(for attaching mounting ears)

4 Self-tapping mounting screws, 12-24

(for rack mounting)

1 Power cable, A/B inputs;18 AWG, 12 ft (3.66 m)

1 Ground cable; 8 AWG, 12 ft (3.66 m), plus termination hardware (2 ea. washers,

nuts)

1 Spare 2-hole ground lug (8 AWG)

4 Cable tie mounts

(for RJ-21 connector using a 90 degree exit)

4 Panhead Phillips screws, 4-40 x .25 inches (.6 cm)

(for securing cable tie mounts to RJ-21 connectors that use a 90 degree exit)

The following optional equipment is ordered and packaged separately, as required:

 Pluggable transceiver modules (required for line termination)

 Fiber guide suitable for all E7-2 deployments, including ETSI racks

 Cool air intake and rear heat exhaust system to redirect airflow to the rear of the chassis

 RS-232 console cable (DB-9F to RJ-11M) to connect to a PC for console management
