Calix E7-2 Installation Guide

54
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
E7-2 Specifications
Specifications for the Calix E7-2 follow:
Dimensions
Chassis 1.7 (H) x 17.5 (W) x 11.45 (D) inches
4.3 (H) x 44.5 (W) x 29.1 (D) cm
Weight
E7-2 chassis only
5.9 lbs (2.7 kg)
E7-2 chassis with FTA
E7-2 chassis with FTA + 2 line cards
7.4 lbs (3.4 kg)
11.5 lbs (5.2 kg)
E7-2 chassis with FTA2
E7-2 chassis with FTA2 + 2 line cards
7.0 lbs (3.2 kg)
11.1 lbs (5.0 kg)
Mounting
Width 19-inch (48.26-cm) and 23-inch (58.42-cm) racks
Depth Front (flush) mounting
Center (projection) mounting, 5 depth options
Orientation Horizontal and vertical mounting supported
Electrical
Power input -48 VDC redundant battery feeds (A and B)
-42.5 VDC to -72 VDC input range
Fusing
7.5 Amps maximum (A and B)
Environmental
Operating range -40º C to +65º C (-40º F to +149º F)
Humidity: 10 to 95% (non-condensing)
Altitude: up to 10,000 feet (3049 m)
Storage range -40º C to +85º C (-40º F to +185º F)
Humidity: 5 to 95%
Heat dissipation (with 2 line cards)
Up to 185 Watts maximum
Fan module cooling capacity FTA: 200 Watts, 108 CFM; (2) automatic variable fan speed
operations
FTA2: 200 Watts, 115 CFM; (4) automatic variable fan speed
operations
Note: FTA2 requires E7 release 2.2 or higher to support four fan
speeds. In releases prior to 2.2, FTA2 supports two fan speeds.
Alarming
8 user definable alarm inputs (7 inputs, 1 output)
Compliance
Compatibility, Electrical Safety, and Electromagnetic
emissions criteria
UL/cUL 60950
European Union EN 60950 (CE Mark)
EIA-310D
FCC Part 15 Class A
Network Equipment-Building System (NEBS) Level 3: Telcordia
GR-63-CORE
Telcordia GR-1089-CORE
Telcordia GR-3028-CORE
ETSI EN 300 019, ETSI 300 386
