Chapter 4
Wiring the E7-2 Network Interfaces
This section describes how to wire out the Calix E7-2 network interfaces, including
management, alarms, and service line interfaces.
Topics Covered
This section covers the following topics:
 Connecting the E7-2 management interfaces
 Wiring the E7-2 alarm and timing interfaces
 Connecting the E7-2 line interfaces
