3. Connect the chassis ground cable to the main ground system (preferred) or to the rack
frame as follows:
a. Route the ground cable to the grounding termination location. If the cable is too
long, cut the cable to length and crimp on an appropriate lug. (A spare lug is included
in the installation kit.)
b. Connect the ground cable to the main ground system or rack frame per PANI
guidelines.
Note: Grounding surfaces must be brought to a bright finish and coated with antioxidant
before being joined. When grounding to a rack frame, ensure that there is no paint or
debris between the ground lug and the rack frame. To ensure a reliable ground bond,
apply an anti-oxidant and use paint piercing star washers and thread forming screws to
secure a metal-to-metal ground contact to the rack frame.
