Port status indicators
Each interface port on an E7-2 line card has an LED located below its module socket to
indicate port status. (E7-2 cards contain a mix of some or all port types listed below).
LED Port Color Status Description
XFP
(1, 2)
10GE Green
Indicates that an Ethernet link has been established
Blinking After module insertion, blinks (3) times to indicate the inserted
module is recognized and allowed to operate
Blinks at variable speeds to indicate the link is
transmitting/receiving traffic
SFP+
(1, 2)
Off Socket is vacant or an invalid module is inserted
Red On Indicates a module has been inserted into a 10GE socket that is
directed to the backplane for connectivity between two cards
(Applies to XFP 2 and SFP+ 2 only)
Indicates that an Ethernet link has been established
Blinking After module insertion, blinks (3) times to indicate the inserted
module is recognized and allowed to operate
Blinks at variable speeds to indicate the link is
transmitting/receiving traffic
Off Socket is vacant or an invalid module is inserted
GPON
(1–4)
GPON Green On Indicates that at least one ONT is in service on the PON
Blinking After module insertion, blinks (3) times to indicate the inserted
module is recognized and allowed to operate
Blinks steadily while the first ONT on the port is ranging
Off Socket is vacant or an invalid module is inserted
