Calix E7-2 Installation Guide

59
Proprietary Information: Not for use or disclosure except by written agreement with Calix.
© Calix. All Rights Reserved.
Pin Color Tip/Ring Circuit Pin Color Tip/Ring Circuit
12 OR/BK Ring 12 37 BK/OR Tip 12
13 GN/BK Ring 13 38 BK/GN Tip 13
14 BR/BK Ring 14 39 BK/BR Tip 14
15 SL/BK Ring 15 40 BK/SL Tip 15
16 BL/YL Ring 16 41 YL/BL Tip 16
17 OR/YL Ring 17 42 YL/OR Tip 17
18 GN/YL Ring 18 43 YL/GN Tip 18
19 BR/YL Ring 19 44 YL/BR Tip 19
20 SL/YL Ring 20 45 YL/SL Tip 20
21 BL/VI Ring 21 46 VI/BL Tip 21
22 OR/VI Ring 22 47 VI/OR Tip 22
23 GN/VI Ring 23 48 VI/GN Tip 23
24 BR/VI Ring 24 49 VI/BR Tip 24
25 SL/VI Not used 50 VI/SL Not used
