1.2 Description
Front panel
Colour LCD touch screen
Health Check
Opens the Health Check menu.
Settings
Opens the Settings menu
Lock
Lock/Unlock the touch screen
Power
Instrument power on/off button.
Press to switch on and to switch off the instrument. In the Stand-by mode, power is
maintained for the internal rubidium timebase, as long as the mains cable is connected to
the mains outlet.
Start/Stop
Measurement start/stop button
Keypad
Buttons for navigation in the menus displayed on the screen
[Enter] Confirm
1
2
4
6
7
3
5
1
2
3
4
5
6
7
