Calorex Pro-Pac PPT45EHC - Controls and Indication Lamps

Pro-Pac 90/140 CONSOLE
KEY
WATER FLOW
HEAT
TEMP OK
CHILL
CHILL LIMIT
1
2
MAINS
FAULT
FRIDGE FAULT 1
FRIDGE FAULT 2
DEFROST
NOT USED
ACCESS SET
POINT
INCREASE SET
POINT
DECREASE SET
POINT
U
P
21
10
AMBER
RED
RED
AMBER
AMBER
AMBER
CLEAR
GREEN
GREEN
RED
STANDBY
SWITCH
THERMOSTAT
‘HC’ HEATER CHILLER
Adjustable two stage digital ermostat controls and maintains heat and
cooling level.
Press and release ‘P’ key to display required temperature, to alter
required temperature press up or down symbols. Aer five seconds
display reverts to actual water temperature.
When adjusting e temperature on a “PPT” Pro-Pac, before changing
e temperature put e machine into standby mode by switching e
standby switch to ‘O’. Aer e temperature has been changed, switch
e standby switch back to ‘I’.
28
SD566250 ISSUE 35
PR0-PAC SYSTEM OWNER INSTALLATION MANUAL
