AIR TO WATER HEAT PUMPS FOR HEATING & COOLING SWIMMING POOLS IN HIGH TEMPERATURE APPLICATIONS.
220V 3~ 60HZ.
model Pro-Pac 30 Pro-Pac 45 Pro-Pac 70 Pro-Pac 90 Pro-Pac 140
UNITS
DUTY
Air On @ 20°C, 70%RH HEATING
Output to water (@ 26ºC) kW 30 32.0 54.0 64.0 108.0
Electrical input kW 6 6.7 11.0 13.4 22.0
Air on @ 40°C, 85%RH COOLING
Output to water (@ 30ºC) kW 21 28 48 56 96
Electrical input kW 6.4 9.1 14.9 18.2 29.8
ELECTRICAL DATA
Electrical supply 3 phase V/ph/Hz |---------------- ----------------- 220V 3~ / 60Hz ---------------- ---------------|
Minimum supply capacity 3 phase A 38 36 59 71 118
Recommended supply fuse 3 phase A 45 50 80 100 160
Max starting current STD (LRA) A 246 265 246 265 246
Max starting current S/Start (LRA) A 23 23 23 24 N/A
AIR DATA
Nominal air flow ± 10% m/h 5500 11000 13650 22000 28000
Fan external resistance Pa 0 0 0 0 0
WATER DATA (PP Pro-Pacs)
Water flow ±10% L/min - 66 133 133 266
Pressure drop (water) m hd - 4.5 3.9 4.5 5.3
Water connections inches |---------------- ----------------- 1½” BSPM ----------------| 2" BSPM
Condensate water connections inches |---------------- ----------------- 1½” BSPM ---------------- ----------------|
PPT Pro-Pacs
Water flow ±10% L/min 250 300 500 600 1000
Pressure drop (water) m hd 0.7 0.35
1.5 1.4 1.4
Water connections inches 2" UNION SKT 2” UNION SKT 3" BSPM 3" BSPM 4" BSPM
GENERAL DATA
Hermetic system
Gas charge (R134a) "PP" Pro-Pacs kg - 16 32 16 x 2 32 x 2
Carbon dioxide equivalent Tonnes - 22.9 45.8 22.9 x 2 45.8 x 2
Gas charge (R134a) "PPT" Pro-Pacs kg 13.7 18.5 30 19.2 x 2 17.5 x 2
Carbon dioxide equivalent Tonnes 19.6 26.5 42.9 27.5 x 2 25 x 2
Compressor type 1 x SCROLL 1 x SCROLL 2 x SCROLL 2 x SCROLL 4 x SCROLL
Fan type 1 x AXIAL 1 x AXIAL 1 x AXIAL 2 x AXIAL 2 x AXIAL
*Sound pressure level @3m AIR ON dB(A) 64 65 70 65 70
*Sound pressure level @3m AIR OFF dB(A) 60 61 64 64 67
*Sound pressure level @3m SIDE dB(A) 61 64 65 61 65
DIMENSION DATA
Wid (unpacked) "PP" Pro-Pacs mm 1555 1665 1810 2065 2210
Wid (unpacked) "PPT" Pro-Pacs mm 1585 1695 1840 2095 2250
Dep (unpacked) mm 790 1060 1190 1190 1650
Height (unpacked) mm 1080 1330 1310 1350 1340
Weight (unpacked) PP Pro-PacS kg TBA 329 543 TBA 1009
Weight (unpacked) PPT Pro-PacS kg 245 322 520 608 1048
Wid (export, packed) mm 1775 1875 2020 2295 2470
Dep (export, packed) mm 900 1170 1300 1310 1770
Height (export, packed) mm 1250 1500
1480 1520 1505
Weight (export, packed) PP Pro-PacS kg TBA 438 657 TBA 1229
Weight (export, packed) PPT Pro-PacS kg 266 444 637 723 1268
NOTES
(1) Weight and dimensions nett.
(2) Allow 500mm clearance to service panels.
(3) Minimum air temperature 7°C.
(4) Water to have correct balance pH 7.2- 7.8. Free Chlorine 1.0-2.0 ppm domestic, 3.0 - 6.0 commercial.
(5) Danerm Ltd. reserves e right to change or modify models wiout prior notice.
(6) R134a Global Warming Potential (GWP) 1430.
*(7) Noise tests performed in accordance wi BS ISO 3744:2010: k factor 0.
