Calorex Pro-Pac PPT45EHC - Page 35

Pro-Pac45 DIMENSIONS IN mm ISSUE 1 ALLOW 500mm FOR ACCESS TO SERVICE PANELS WATER CONNECTIONS 1½" BSPM CONDENSATE 1½" BSPM
SERVICE
PANEL
NOMINAL FAN
DIAMETER 730
SERVICE
PANEL
735
610
SERVICE
PANEL
AIR IN
AIR OUT
CONSOLE
HP SWITCH
LP SWITCH
CHILL LIMIT SWITCH
SERVICE PANEL
ELECTRIC BOX
ACCESS
SERVICE
PANEL
MAINS IN
U P
10
RED
AMBER
RED
AMBER
RED
GREEN
GREEN
CLEAR
* FIXING CENTRES TO SECURE MACHINE
*970
1590
1665
WATER
IN
WATER
OUT
1054
CONDENSATE OUT
POSITION IN BASE
*985
235
502
65
1060
1330
SERVICE
PANEL
850
CONDENSATE OUT
POSITION IN BASE
35
SD566250 ISSUE 35
