Calorex Pro-Pac PPT45EHC - Page 45

Pro-Pac PPT140EHC
DIMENSIONS IN mm
ISSUE 3
LEAVE 500mm CLEARANCE FOR SERVICE PANELS
WATER CONNECTIONS 3" BSPM CONDENSATE 1½" BSPM
SERVICE PANEL SERVICE PANEL
SERVICE PANEL
NOMINAL FAN
DIAMETER 815
821
514.50
1437.50
CHILL
LIMIT
2146
2210
*1616
1290
CONDENSATE OUT
POSITION IN BASE
SERVICE PANEL
ELECTRIC BOX
ACCESS
1650
SERVICE PANEL
MAINS
HP LP
CHILL
LIMIT
CONSOLE
HP
LP
U P
21
10
AMBER
RED
RED
AMBER
AMBER AMBER
CLEAR
GREEN
GREEN
RED
*1562
CONDENSATE OUT
POSITIONS IN BASE
FAN 1
FAN 2
AIR OFF
SERVICE
PANEL
AIR ON
*FIXING CENTRES FOR SECURING MACHINE
WATER
OUT
WATER
IN
AIR ON
385
822
1340
598
SWITCHES
SWITCHES
254
254
45
SD566250 ISSUE 35
