Page 24 - Manual FA01295-EN - 03/2023 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Hold-to-run
With the function active, the operator stops moving (opening contact 2-3 or closing contact 2-4) when the control device is released.
When the function is active, it excludes all other control devices.
F6 Hold-to-run OFF (Default)
ON
Command 2-7
Associate a command to the connected device on 2-7.
F7 Command 2-7 0 = Step-by-step (default) - The first command is to open and the second to close.
1 = Sequential - The first command is to open, the second to STOP, the third to close and
the fourth to STOP.
Obstacle with motor stopped
With the function active, the gate remains idle if the safety devices detect an obstacle. The function is active when the gate is closed, open or after a complete stop.
F9 Obstacle with motor stopped OFF (Default)
ON
Passage-open warning light
It notifies the user of the operator status.
F10 Passage-open warning light 0 = Warning light on (default) - The warning light stays on when the gate is moving or
open.
1 = Warning light flashing - The warning light flashes every half second when the gate is
opening and stays on when the gate is open. The light flashes every second when the gate
is closing, and remains off when the gate is closed.
Sensor type
Choose the type of control device.
F14 Sensor type 1 = Keypad selector (default)
0 = Transponder selector or magnetic card reader
Additional light
Choose the operating mode of the lighting device connected to the output W-EX.
F18 Additional light OFF (Default)
1 = Cycle light - The lamp stays on during the manoeuvre.
The light remains off if an automatic closing time is not set.
This parameter does not appear if the [F19 - Automatic Close] function is
deactivated.
2 = Courtesy lamp - The light switches on when a manoeuvre starts and remains on once
the manoeuvre has finished, for the time set under the function [F25 Courtesy time].
Automatic closure
Set the time before automatic closure, once the opening travel end point has been reached.
The function does not work if any of the safety devices are triggered when an obstacle is detected, or after a complete stop, or during a power outage.
F19 Automatic closure OFF (Default)
1 to 180 seconds
1 to 180 seconds
180 = 180 seconds
Automatic closing after partial opening
Set the time before automatic closure after a partial opening command.
The function does not work if any of the safety devices are triggered when an obstacle is detected, or after a complete stop, or during a power outage.
F20 Automatic closing after partial
opening
OFF
1 to 180 seconds (Default 10)
