Page 25 - Manual FA01295-EN - 03/2023 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
Pre-flashing time
Adjust the time for which the beacon connected to E1-W is activated before each manoeuvre.
F21 Pre-flashing time OFF (Default)
1 to 10 seconds
Courtesy light time
Define how many seconds the additional light (set up as courtesy light) stays on after an opening or closing manoeuvre.
F25 Courtesy light time 60 to 180 seconds (Default 60)
RSE communication
Configure the function performed by the board connected to the RSE connector.
F49 RSE communication OFF (Default)
1 = Paired
3 = CRP
Save data
Save user data, timings and configurations to the memory device (memory roll).
The function is displayed only when a memory roll card is inserted into the control board.
F50 Save data OFF (Default)
ON (Run operation)
Read data
Upload user data, timings and configurations to the memory device (memory roll).
The function is displayed only when a memory roll card is inserted into the control board.
F51 Read data OFF (Default)
ON (Run operation)
Transferring MASTER-SLAVE parameters
Share the parameters programmed on the master gate with the slave gate.
This function appears only if the [F49 – RSE communication] function is set to 1.
F52 Transferring MASTER-SLAVE
parameters
OFF (Default)
ON
Opening direction
Set the gate opening direction.
F54 Opening direction 0 = To the left (default)
1 = To the right
CRP address
Assign a unique identification code (CRP address) to the control board.
The function is used where there are multiple operators connected to the same communication BUS using the CRP protocol.
F56 CRP address from 1 to 255
RSE speed
Set the communication speed of the remote connection system.
F63 RSE speed 0 = 1200 bps
1 = 2400 bps
2 = 4800 bps
3 = 9600 bps
4 = 14400 bps
5 = 19200 bps
6 = 38400 bps (default)
7 = 57600 bps
8 = 115200 bps
