p. 20 - Manual FA00945-EN - 01/2018 - © CAME S.p.A. - Translated original instructions
F5 Safety test
After every opening or closing command, the board will check whether the photocells are working properly.
The safety test is always active for wireless devices.
This function only appears if the photocells have been enabled.
OFF= Deactivated (default) / 1=CX / 2=CY / 4=CX+CY
F6 Maintained action
The gate opens and closes by keeping the button pressed. Opening button on contact 2-3P and closing
button on contact 2-7. All other control devices, even radio-based ones, are excluded.
OFF (default) / ON
F7 Command [2-7]
From the control device connected to 2-7, it performs the (open-close-invert) step-step, (open-stop-close-
stop), sequential, open or close command
0 = Step-step (default) / 1 = Sequential / 2 = Open / 3 = Close
F8 Command (2-3P)
From the control device connected to 2-3P, it performs a partial opening or only opening of the gate.
0 = Partial opening (default) / 1 = Open
F9
Obstruction detection
with motor stopped
With the gate closed, opened or totally stopped, the gearmotor stays idle if the safety devices, that is,
photocells or sensitive safety-edges detect an obstruction.
OFF (default) / ON
F11 Encoder
Managing slow-downs, obstruction detections and sensitivity.
OFF / ON (default)
F14 Sensor type
Setting the type of accessory for controlling the operator.
0 = command with transponder sensor or magnetic card reader / 1 = command with keypad selector
(default)
F18 Additional light
Additional light connection input on W-E1.
Flashing light: it fl ashes during the gate's opening and closing phases.
Cycle light: additional external light for increasing illumination in the drive way. It stays on from the moment
the leaf starts opening until it again closes completely - including the waiting time before the automatic-
closing time.
The cycle light setting appears only of the automatic closing is activated.
OFF = Flashing light (default) / 1 = Cycle
F19 Automatic Closing Time
The automatic-closing wait starts when the opening limit switch point is reached and can be set to between
1 and 180 seconds. The automatic closing does not work if any of the safety devices trigger when an
obstruction is detected, or after a total stop, or during a power outage.
OFF (default) / 1 = 1 second /... / 180 = 180 seconds
F20
Automatic closing time
after partial opening
The wait before the automatic closing starts after a partial opening command for a time of between 1 s
and 180 s. The automatic closing does not work if any of the safety devices trigger when an obstruction is
detected, or after a total stop, or during a power outage.
OFF / 1 = 1 second /... / 10 = 10 seconds (default) / 180 = 180 seconds
F21 Pre-fl ashing time
Adjusting the pre-fl ashing time for the fl ashing light connected to W-E1 before each maneuver. The fl ashing
time is adjustable from one to ten seconds.
OFF (default) / 1 = 1 second /... / 10 = 10 seconds
F30
Opening and closing
slow-down speed
Gate slow-down speed before the limit-switch when opening and closing.
This function only appears if the Encoder function is activated.
OFF (default) / 1 = High / 2 = Average / 3 = Low
F34 Travel sensitivity
Adjusting obstruction detection sensitivity during gate-leaf travel.
This function only appears if the Encoder function is activated.
10 = maximum sensitivity / … / 100 = minimum sensitivity (default)
F35 Slow-down sensitivity
Adjusting obstruction detection sensitivity during slow-down.
This function only appears when functions F11 and F30 are activated.
10 = maximum sensitivity / … / 100 = minimum sensitivity (default)
F36
Adjusting the partial
opening
Adjustment as a percentage of total travel, during gate opening.
This function only appears if the Encoder function is activated.
10 = 10% of the gate travel /... / 80 = 80% of the gate travel (default)
F37
Opening slow-down
point
Percentage adjustment of the total door travel, of the opening slow-down starting point.
This function only appears when functions F11 and F30 are activated.
5 = 5% of the gate travel /... / 15 = 15% of gate travel (default) /... / 30 = 30% of gate travel
