CAME BXV Series User Manual

p. 28 - Manual FA01294-EN - 12/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Original instructions
Export / import data
It is possible to save user data and system configuration in a MEMORY ROLL card.
The stored data can be reused in another electronic board to configure another system in the same way.
Before fitting and removing the MEMORY ROLL card, you MUST CUT OFF THE MAINS POWER SUPPLY.
1 - Fit the MEMORY ROLL card into the corresponding connector on the control board.
2 - Press the Enter button to access the programming.
3 - Use the arrows to choose the desired function.
The functions are displayed only when a MEMORY ROLL card is inserted.
- Saving data
Save user data, timings and configurations to the memory device (memory roll or USB key).
- Data reading
Loads user data, timings and configurations from the memory device (memory roll or USB key).
When the data saving and loading operations have been completed, remove the MEMORY ROLL card.

CAME BXV Series Specifications

General

Encoder	Yes
Power Supply	230V AC, 50Hz
Max Door Weight	800kg
Duty Cycle	30%
Lifting Capacity	800kg
Power Consumption	370W
Remote Control	Yes
Battery Backup	Optional
