p. 27 - Manual FA01294-EN - 12/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Original instructions
Parameters reset
The default settings are restored and the travel calibration is deleted.
A4 Parameters reset OFF (Default)
ON
Manoeuvres counter
For viewing the number of maneuvers made by the operator.
A5 Manoeuvres counter 001 = 100 maneuvers
010 = 1000 maneuvers
100 = 10000 maneuvers
999 = 99900 maneuvers
CSI = maintenance job
Adjusting the motor torque
Adjust the motor torque.
A6 Adjusting the motor torque From 1 (minimum) to 5 (maximum)
FW version
Displays the number of the firmware version and GUI installed.
H1 FW version
Getting started
Once the electrical connections have been completed, proceed with commissioning. Only skilled and qualified staff may perform this operation.
Make sure that the way is clear from any obstruction.
Power up and begin programming.
Start programming with the following functions: F54 (Opening direction) and F1 (Total Stop).
After powering up the system, the first maneuver is always the opening; wait for the maneuver to be completed.
Immediately press the STOP button if any suspicious malfunctions, noises or vibrations occur in the system.
At the end of commissioning, check the correct operation of the device using the buttons near the display. Check that the accessories also work correctly.
