p. 26 - Manual FA01294-EN - 12/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Original instructions
Add User
It is used to register a maximum of 250 users and assign a function to each one.
The operation can be carried out by using a transmitter or other control device. The boards that manage the control devices (AF - R700 - R800) must be
plugged into the connectors.
From the docs.came.com portal, download the LIST OF REGISTERED USERS form, type L20180423.
U1 Add User 1 = Step-step
2 = Sequential
3 = Open
4 = Partial opening
1 - Choose the function to be assigned to the user.
2 - Press ENTER to confirm.
The user code must be entered.
3 - Send the code from the control device.
Repeat the procedure for adding other users.
Remove user
Removes one of the registered users.
U2 Remove user OFF
ON
Use the arrows to choose the number associated with the user to be removed.
Alternatively, the control device associated with the user to be removed can be
activated.
Press ENTER to confirm.
The Clr wording will appear to confirm the deletion.
Remove all
Removes all registered users.
U3 Remove all 0 =Deactivated (Default)
1 = Deletion
Radio-frequency decoding
For choosing the type of radio coding of the transmitters enabled to control the automation.
Choosing the type of radio coding of the transmitters [Rolling code] or [TW key block], the transmitters with different type of radio coding previously
stored, will be deleted.
U4 Radio-frequency decoding 1 = All (Default)
2 = Rolling code
3 = TWIN
Motor type
It is used to set the type of gearmotor installed.
A1 Motor type 1 = 400 kg
2 = 600 kg
3 = 800 kg
4 = 1000 kg
Travel calibration
Starts the travel self-learning.
A3 Travel calibration OFF
ON
