CAME BXV Series User Manual

p. 25 - Manual FA01294-EN - 12/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Original instructions
RSE speed
It is used to set the remote connection system communication speed on the RSE port.
F63 RSE speed 0 = 1200 bps
1 = 2400 bps
2 = 4800 bps
3 = 9600 bps
4 = 14400 bps
5 = 19200 bps
6 = 38400 bps (Default)
7 = 57600 bps
8 = 115200 bps
RIO ED T1
It is used to associate a function among those available to a wireless safety device.
The function appears only if there is an interface board for wireless devices.
F65 RIO ED T1 OFF (Default)
P0
P7
P8
RIO PH T1
It is used to associate a function among those available to a wireless safety device.
The function appears only if there is an interface board for wireless devices.
F67 RIO PH T1 OFF (Default)
P0
P7
P8
RIO PH T1
It is used to associate a function among those available to a wireless safety device.
The function appears only if there is an interface board for wireless devices.
F67 RIO PH T1 OFF
P1 (Default)
P2
P3
P4
RIO PH T2
It is used to associate a function among those available to a wireless safety device.
The function appears only if there is an interface board for wireless devices.
F68 RIO PH T2 OFF
P1 (Default)
P2
P3
P4
Partial opening time
It is used to adjust the gate opening time.
This function only appears if the [Encoder] function is deactivated.
F71 Partial opening time From 5 to 40 seconds

CAME BXV Series Specifications

General

Encoder	Yes
Power Supply	230V AC, 50Hz
Max Door Weight	800kg
Duty Cycle	30%
Lifting Capacity	800kg
Power Consumption	370W
Remote Control	Yes
Battery Backup	Optional
