Manual FA01175-EN - 05/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice.
-
Translated original instructions
Legend of symbols
This symbol tells you to read the section with particular care.
This symbol tells you that the sections concern safety issues.
This symbol tells you what to say to the end-users.
Intended use
The FERNI 230V operator is specifi cally engineered to automate residential and condominium swing gates.
The use of this product for purposes other than those described above and installation executed in a manner other than as instructed in
this technical manual are prohibited.
Restrictions
Gearmotor
Description
Technical features
Gate leaf width
m
Gate leaf weight
kg
2.00 800
2.50 600
3.00 500
3.50 450
4.00 400
Version F1000
Irreversible gearmotor
Motor power supply: 230V a.c. 50/60Hz
Max draw: 1,3A
Power: 150W
Gear ratio: 1/709
Opening time (90°): 18 s
Max. torque: 320 Nm
Duty Cycle: 30%
Protection Rating: IP54
Weight: 14 kg
Operating temperature
Version F1100
Reversible gearmotor
Motor power supply: 230V a.c. 50/60Hz
Max draw: 1A
Power: 110W
Gear ratio: 1/678
Opening time (90°): 18 s
Max. torque: 380 Nm
Duty Cycle: 50%
Protection Rating: IP54
Weight: 13 kg
Operating temperature
Intended use and restrictions
This product is engineered and manufactured by CAME S.p.A. and complies with current safety regulations.
The gearmotor is composed of two, cast aluminium half shells inside of which rest the gearmotor and endstops – with electro blo-
cking – and an endless screw, epicycloidal gear reduction system.
Lengt of gate wings: up to 4 metres. Max. angle of gate wing when open: 90°.
We suggest you always fit an electrolock onto swing gates for a more reliable closure.
Fitting electrolocks onto reversible operators makes for anti-intrusion security.
You must install electrolocks onto irreversible operators with gate leaves exceeding 2.5 m.
