CAME F1000 User Manual

WVU
XVUYW
Manual FA01175-EN - 05/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice.
-
Translated original instructions
For electrical connection operations, use the chamber and the junction boxes.
For further information regarding functions and adjustment, refer to the technical documentation for the control panel.
Electrical connections
Maintenance
Periodic maintenance log kept by users (every six months)
Date Notes Signature
Periodic maintenance
☞
Before doing any maintenance, cut off the power supply, to prevent any hazardous situations caused by accidentally activating the operator.
Motor 1: U - V - W
Motor 2: X - Y - W
Motor terminals
Control panel terminal board
Ground
 If only using one motor, such as with one-leaf gates, connect it to W X Y (M2) regardless of which side it is installed on.
