7 02/2016
© CAME S.p.A. - The data and information provided in this manual are subject to change at any time without prior notice by CAME S.p.A.
With swing gates it is always advisable to install and electro-lock. This is to ensure a reliable closing and to protect the gearmotor’s inner workings.
But whereas with reversible operators it is merely advisable, with irreversible ones, beyond 2.5 m, it is obligatory.
KEY
This symbol indicates parts to read carefully.
⚠
This symbol indicates parts about safety.
☞
This symbol tells you what to say to the end users.
DESCRIPTION
The product consists of: a foundation box, a gearmotor and motion transmission arms.
Intended use
Designed to power swing gates for residential or condominium use.
Any installation and operation that differs from what is set out in this manual is prohibited.
Model FROG-A / FROG-AE
Max. leaf length (m) 3.5 2.5 2.0
Max. leaf weight (kg) 400 600 800
Model FROG-AV
Max. leaf length (m) 1.3
Max. leaf weight (kg) 300
Limits of use
Technical data
Type FROG-A / FROG-AE FROG-AV
Protection rating (IP) 67 67
Power supply
(V - 50/60 Hz)
230 AC 230 AC
Motor power supply (V - 50/60 Hz) 230 AC 230 AC
Power draw (A) 1.9 max. 2.5 max.
Power (W) 200 300
Thrust (N) 320 max. 240 max.
Opening time to 90° (sec) 18 9
Duty Cycle (%) 30% 30%
Operating temperature (°C) -20 - +55 -20 - +55
Motor thermal protection (°C) 150 150
Gear ratio 1/1152 1/1152
Insulation class I I
Weight (kg) 11 11
THE MEASUREMENTS, UNLESS OTHERWISE STATED, ARE IN MILLIMETERS.
