Page 13 - Manual FA01569-EN - 04/2021 - © CAME S.p.A. - The contents of this manual may be changed at any time and without notice. - Translation of the original instructions
FINAL OPERATIONS
OUTWARDS OPENING
The operations other than the standard installation are described below.
Setting up the gearmotor
Insert the closing limit-switch point adjustment screw into the gearmotor arm.
A
Gearmotor installed on the left
B
Gearmotor installed on the right

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the CAME FROG and is the answer not in the manual?

CAME FROG Specifications

General IconGeneral
Motor Power300 W
Max Gate Weight800 kg
ModelFROG
Motor Voltage230 V AC
Operating Temperature-20°C to +55°C
Power Supply230V AC
