ENGLISH
Calculate the am
length and that of the
anti-impact profi le by
using as reference the
passage width room.If
necessary, cut any extra
parts.
Insert the anti-impact profi le into the lower part of the arm.
Length of arm
Length of anti-impact profile
passage width room (3250 mm max.)
Length of cord = l x 2 + 0.5 m
The luminous cord may be cut only at the points
indicated by the scissors (i.e. at each meter)
