CAME STYLO Series - Mechanical Stop Positioning; Opening Stop Adjustment; Closing Stop Adjustment

➊
➋
➊
➋
Pag.
13
13 -
Manual code
:
119DV11
119DV11 ver.
1.0
1.0 03/2010
© CAME cancelli automatici s.p.a. -
The data and information reported in this installation manual are susceptible to change at any time and without obligation on CAME cancelli automatici s.p.a. to notify users.
ENGLISH
Release the gearmotor (see
paragraph on manual release)
Fully open the gate leaf, position
the mechanical stop so that it
coincides with the slide guide
and secure it.
Insert the end caps of the rail and the
hole covers.
Fully close the gate leaf and position the closing
mechanical stop so that it coincides with the slide guide
and then secure it.
