Page 15 - Manual FA01799 -EN - 04/2022 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Release the operator
ELECTRICAL CONNECTIONS
⚠
Before powering up the board, cut off the mains power supply.
Power supply (V - 50/60 Hz): 230 AC
Board functions:
• Movement control and obstacle detection
• Reopen during closing
• Adjustable automatic reclosing time
• Open-stop-close-stop from transmitter and/or from button
• Courtesy light (at each opening command, the courtesy light stays on for three minutes)
LIGHTS
LED courtesy (W) ≤ 1
Release
To release the operator, pull down the cord ⓒ.
Locking
To lock the operator back up, use the transmitter or the control button.
Page 15 - Manual FA01799 -EN - 04/2022 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
