④
①
⑭
⑬
⑫⑪⑩⑨
④
④
⑥
⑧
②
③
Page 7 - Manual FA01799 -EN - 04/2022 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Translation of the original instructions
Packing list
① one Operator
② one Installation Manual
③ two anchoring perforated-plates
④ one Curved lever
⑤ Two support braces
⑥ Three U-shaped braces
⑦ One guide-fitting brace
⑧ One door fitting brace
⑨ Eight self-drilling hexagonal head M6x15 screws
⑩ One hexagonal M6x80 nut and bolt
⑪ One (Ø8x25) drive-shaft adapter
⑫ One 3x20 linchpin
⑬ One pin
⑭ Four M8X20 hexagonal screws with washers and nuts
Page 7 - Manual FA01799 -EN - 04/2022 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice. - Original instructions
