CAME VER12 Installation Manual

p.
4
4 - Manual
FA00045-EN
FA00045-EN v.
2
2 - 09/2016 - © Came S.p.A. - The contents of this manual may be changed, at any time, and without notice.
LEGEND

This symbol shows which parts to read carefully.
⚠
This symbol shows which parts describe safety issues
☞
This symbol shows which parts to tell users about.
UNLESS OTHERWISE STATED, THESE OPERATIONS APPLY TO ALL MODELS.
T
HE MEASUREMENTS, UNLESS OTHERWISE STATED, ARE IN MILLIMETERS.
DESCRIPTION
Operator, complete with control board with encoder, for sectional and overhead garage-doors.
Intended use
The VER10 - VER12 are designed to power overhead garage doors in residential and apartment block
settings.
 Any installation and/or use other than that specified in this manual is forbidden.
Limits to use
Type VER10 VER12
Door's max. surface area (m
2
)1821
Counter-weighted overhead door's max. weight (m) 2.40 2.40
Maximum height of spring-balanced overhead doors (m) 3.25 3.25
Maximum height of door (m) 3.20 3.20
Technical data
Type VER10 VER12
Protection rating (IP) 30 30
Power supply (V - 50/60 Hz) 230 AC 230 AC
Power supply motor (V) 24 DC 24 DC
Stand-by consumption (W) 5 7.5
Maximum power of the accessories (W) 40 40
Nominal power (W) 130 260
Maneuvering speed (m/min) 6 6
Duty cycle (%) 50 50
Traction force (N) 1,000 1,200
Operating temperature (°C) -20 ÷ +55 -20 ÷ +55
Apparatus class I I
Weight (Kg) 5.7 5.8
