Applicative examples
Sectional door with single
slide-guide
Sectional door with double
slide-guides
SECTIONAL DOOR
COUNTERBALANCED OVERHEAD DOOR,
PARTIALLY RETRACTING AND PROTRUDING
SPRING-BALANCED OVERHEAD DOOR,
FULLY RETRACTING AND PROTRUDING
INSTALLATION
⚠
The following illustrations are just examples, in that the space available for fitting the operator and
accessories varies depending on the overall dimensions. It is up to the installer to find the most suitable
solution.
Assembling the traction guide
