Traction guides
001V0679 Chain guide L = 3.02 m.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional doors* up to 2.20 m in height.
001V0682 Chain guide T = 3.52 m.
- Counter-balanced overhead doors up to 2.75 m in height.
- Sectional* doors up to 2.70 m in height.
001V0683 Chain guide L = 4.02 M OF ONE PIECE.
- Spring-balanced overhead doors up to 3.25 m in height.
- Sectional* doors up to 3.20 m in height.
001V0684 Chain guide L = 3.02 M IN TWO PIECES.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional doors* up to 2.20 m in height.
001V0685 Belt guide T = 3.02 m.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional* doors up to 2.20 m in height.
001
001V0686 Belt guide T = 3.52 m.
- Counter-balanced overhead doors up to 2.75 m in height.
- Sectional* doors up to 2.70 m in height.
001
001V0687 Chain guide L = 3.02 in two pieces.
Counter-balanced overhead doors up to 2.4 m in height
- Counter-balanced overhead doors up to 2.25 m in height
- Sectional doors* up to 2.20 m in height.
001V0688 Belt guide T = 4.02 m.
- Spring-balanced overhead doors up to 3.25 m in height
- Sectional* doors up to 3.20 m in height.
☞
(*) For sectional doors, see the paragraph on APPLICATION EXAMPLES
Accessories
001
001V005 Extension for the following types of chain guides: V0679, V0682, V0683, V0684.
001
001V201 Transmission arm for partially retracting overhead garage-doors.
001
001V122
Transmission arm for sectional doors having a top-rail to spring-pole assembly distance compri-
sed between 300 and 600 mm.
001V121 Pull-cord auto-resetting release device to fi t onto the door handle.
001V670
Card for operation during power outages and for recharging the batteries.
To 12 V - 1.2 Ah batteries (not supplied).
GENERAL INSTRUCTIONS FOR INSTALLING
⚠
Only skilled, qualified staff must install this product.
⚠
If the door is fitted with a pedestrian door, you must also fit a safety switch at the entrance, to stop the
operator from working when the pedestrian door is open.
