CAME ZC3 Installation Manual

UVWEEX
C-BX
F4000
2C1CXFCFA
F
B1 B2
Pag.
5
-
manual code
319S33EN
319S33EN ver.
5
06/2015
© CAME S.p.A.- The data and information in this manual may be changed at any time and without obligation on the part of CAME S.p.A. to notify said changes.
4) insert the hinge into the housing (either left or right) and secure them using
the issued screws and washers.
5) Snap the cover onto the hinges.
6) After adjusting and setting, secure the cover using
the issued screws.
15 mm ~
slide the hinges to rotate
them
6 Electrical connections
Single Phase 230 V AC motor
Gearmotor
Limit switches installed:
FA-F = Limit switch opens (contact NC);
FC-F = Contact closes (NC).
If not connected, short circuit the relative termi-
nals.
