The data and information provided in this manual are subject to change at any time without prior notice.
Page
6 - Manual code:
319T07EN
ver.
3 05/2014 © CAME cancelli automatici S.p.A.
Types of cables and minimum thicknesses
☞ If the cables differ in length compared to what is shown in the table, the cable cross-section is determined according to the
actual current draw of the devices connected and according to the provisions of the IEC EN 60204-1 standard.
For connections that require several, sequential loads, the sizes given on the table must be re-evaluated based on actual power
draw and distances. When connecting products that are not specified in this manual, please refer to the documentation provided
with said products.
Connection Type of cable
Cable length
1 < 10 m
Cable length
10 < 20 m
Cable length
20 < 30 m
230 VAC panel power supply
FROR CEI
20-22
IEC EN
50267-2-1
3G 1.5mm² 3G 2.5mm² 3G 4mm²
230 VAC motor power supply 4G 1mm ² 4G 1.5mm² 4G 2.5mm²
Flashing light 2 x 0.5mm² 2 x 1mm² 2 x 1.5mm²
24 V accessory power supply 2 x 0.5mm² 2 x 0.5mm² 2 x 1mm²
24 V Courtesy light 2 x 0.5mm² 2 x 0.5mm² 2 x 1mm²
Control and safety devices 2 x 0.5mm² 2 x 0.5mm² 2 x 0.5mm²
Antenna connection RG58 - max. 10 m
